![](/uploads/sensor-detector/motion-detectors/_110f22e.jpg) |
PDF | Size:Byte |
|
|
|
Wire and wireless compatible | Multi grades sensitivity adjustable | Its K-Band technology can prevent wrong alarm better and increase the sensitivity. | Adopts self-designed DSP chip with DMF (Digital Matrixing Focus) technology. | Dual PIR+MW+Intelligent | Professional lens with UV resistance | Adopts parabola viewfinder,distance and angle can be adjusted flexibly,which has matched the sensitivity far and near. | Remarkable small animals immunity below 30kg | Self-adaption style detection doorsill technology,effective clearance of external interference | Motion intrusion direction selectable,can recognize the master from the illegal intruder. |
|
|
|
|
|
|
Description: |
|
|
|
|
|
|
|
|
Model |
DDT86 |
DDT86DMF |
DDT86DMT |
Detection distance |
12m*12m
|
12m*12m
|
12m*12m
|
Sensor |
Low noise,high sensitivity,Anti-RFI/EMI Dual-E PIR
|
Intelligent mode |
|
DMF
|
DMT
|
MW frequency |
10.525GHz
|
10.525GHz
|
10.525GHz
|
Detecting speed |
0.2m/s-3.5m/s |
Sensitivity |
Self-adaption of frequency tracing |
Alarm-output |
NC Contact rating AV/DC 30V/0.1mA |
Supply& current |
7.5-15V/DC 30mA |
Temp & humidity |
-30癈-70癈 5%-95% (RH) |
PIR zones |
9+5+3=17
|
Installation height |
1.8m-2.4m |
Installation way |
Top-mounting |
Tamper output |
NC Contact rating AV/DC 28V/0.2mA |
Pet immunity |
|
20Kg
|
30Kg
|
Anti-white light |
>=8000LUX |
Anti-RFI/EMI |
20V/m(10MHz-100MHz) |
Apply range |
Indoor |
relay |
Solid state relay |
Remark |
|
|
| |
|
|
