• FIRE SOUNDER F-150
  • Click:
F-150

FIRE SOUNDER

Available In Red

  • Operating Voltage:20-28
  • Rated Current:30
  • Rated Voltage:24VDC
  • Sound Pressure:103
  • G.W(kgs):13.5
  • Capacity(pcs):100
  • Packing Size(mm):580*240*450
  • cart
Description:
6" Fire Alarm Bell Low current consumption Quickly and easily installed Excellent sonorous tone 95dBA at 1 metre Slim profile Fully suppressed and polarised Multi-fixing base plate Features
Rated Voltage
+ 20% 24 Vdc
Rated Current
+ 20% 11 mA/20mA
Sound Output @24V
95dBA@1m
Temperature Range
-10 C to +50 C
Humidity Range
45-85%
Weight
0.95kg
Gong Colour
Red
  The innovative and robust motor driven fire alarm
bell offers excellent sonorous tone, high sound
output and proven reliability with some models only
drawing 11mA. The 150mm (6 inch) version
features the revolutionary aluminium gong offering
enhanced acoustics and greater sound output.
Improved design means easier and quicker
installation. The low profile design meets the
aesthetic requirements of architects and specifiers.

Remark: 3”, 4”, 6”, 8” Available
