Model No.: 2EDGK-508
PLUGGABLE Terminal Block 2EDGK-508

5.08mm

Voltage rating:250VAC Current rating:15Amps/way max. Insulation resistance:5000M/1000V Wire range:14-22AWG Operation temperature:-33 to+120 Torque:4kg-cm/M2.5 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGK-508PLUGGABLE Terminal Block 2EDGK-508
Model No.: 2EDGV-508
PLUGGABLE Terminal Block 2EDGV-508

5.08mm

Voltage rating:250VAC Current rating:15Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGV-508PLUGGABLE Terminal Block 2EDGV-508
Model No.: 2EDGR-508
PLUGGABLE Terminal Block 2EDGR-508

5.08mm

Voltage rating:250VAC Current rating:15Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGR-508PLUGGABLE Terminal Block 2EDGR-508
Model No.: 2EDGKA-508
PLUGGABLE Terminal Block 2EDGKA-508

5.08mm

Voltage rating:300VAC Current rating:15Amps/way max. Insulation resistance:5000M/1000V Wire range:14-24AWG Operation temperature:-40 to+105 Torque:4kg-cm/M2.5
PLUGGABLE Terminal Block 2EDGKA-508PLUGGABLE Terminal Block 2EDGKA-508
Model No.: 2EDGVC-508
PLUGGABLE Terminal Block 2EDGVC-508

5.08mm

Voltage rating:300VAC Current rating:15Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGVC-508PLUGGABLE Terminal Block 2EDGVC-508
Model No.: 2EDGRC-508
PLUGGABLE Terminal Block 2EDGRC-508

5.08mm

Voltage rating:300VAC Current rating:15Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGRC-508PLUGGABLE Terminal Block 2EDGRC-508
Model No.: 2EDGK-381
PLUGGABLE Terminal Block 2EDGK-381

3.81mm

Voltage rating:125VAC Current rating:8Amps/way max. Insulation resistance:5000M/1000V Wire range:16-26AWG Operation temperature:-33 to+120 Torque:2kg-cm/M2 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGK-381PLUGGABLE Terminal Block 2EDGK-381
Model No.: 2EDGV-381 / 2EDGV-350
PLUGGABLE Terminal Block 2EDGV-381 / 2EDGV-350

3.81mm

Voltage rating:125VAC Current rating:8Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGV-381 / 2EDGV-350PLUGGABLE Terminal Block 2EDGV-381 / 2EDGV-350
Model No.: 2EDGR-381
PLUGGABLE Terminal Block 2EDGR-381

3.81mm

Voltage rating:125VAC Current rating:8Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105 Satety apporval:<img src="/templets/images/dswbrand/r.gif">
PLUGGABLE Terminal Block 2EDGR-381PLUGGABLE Terminal Block 2EDGR-381
Model No.: 2EDGIK-508
PLUGGABLE Terminal Block 2EDGIK-508

5.08mm

Voltage rating:300VAC Current rating:12Amps/way max. Insulation resistance:5000M/500V Wire range:14-26AWG Operation temperature:55 to+105
PLUGGABLE Terminal Block 2EDGIK-508PLUGGABLE Terminal Block 2EDGIK-508
Model No.: 508K-508
PLUGGABLE Terminal Block 508K-508

5.08mm

Voltage rating:300VAC Current rating:10Amps/way max. Insulation resistance:500M/500V Operation temperature:55 to+105
PLUGGABLE Terminal Block 508K-508PLUGGABLE Terminal Block 508K-508
Model No.: 508R-508 / 508V-508
PLUGGABLE Terminal Block 508R-508 / 508V-508

5.08mm

Voltage rating:300VAC Current rating:10Amps/way max. Insulation resistance:500M/500V Operation temperature:-40 to+105
PLUGGABLE Terminal Block 508R-508 / 508V-508PLUGGABLE Terminal Block 508R-508 / 508V-508
