• PCB Terminal Block 145R-500 / 145V-500
  • Click:
145R-500 / 145V-500

PCB Terminal Block

5.00/7.50mm

  • Voltage rating:300VAC
  • Current rating:15Amps/way max.
  • Insulation resistance:1000M/500V
  • Wire range:12-22AWG
  • Operation temperature:-40 to+105
  • Screw Torque Value:4kg-cm/M2.5
  • cart
Description:
  • PCB Terminal Block
Housing:Polyester Green Solder Pin:Brass0.8t,Solder Plated Wire Cage:Steel, 0.7t, Zinc Plated Screw:Steel, Zinc Plated
